LIGHTCUBE 851 RGB 10W

The LightCube 851 RGB 10W is a full color white light laser in a submersible waterproof housing rated to IP68, with a typical output power of 10.6W

Guaranteed Visible Power
10 W
Color Output
Full Color
Max Scanner Speed
45kpps @8°
Max Scan Angle
60 °

Included Ilda Interlock Connector, Safety Unit Pro

Availability In stock, ready to ship

DELIVERING ANYWHERE
IN THE WORLD
1-888-LASER-08
toll free
Need help with the tech terms?

LIGHTCUBE 851 RGB 10W

The LightCube 851 Series is an all-weather, outdoor laser solution that is permantly submersible

The LightCube 851 RGB 10W has a maximal output power of 10.6W and a guaranteed output power of 10W.

The LightCube 851 Series is an all-weather outdoor solution. Its waterproof IP68 housing is especially designed for outdoor events - even in combination with water and at bad conditions. The whole projector can even be submerged. It is suitable for fixed installations as well as for mobile use.

This RGB white light laser projector is a pure diode device with great beam quality, modulation and a, linear color fading. It is equipped with the fast Apollo ScannerMax scanning system, which enables a scan angle of up to 60° and a scan speed of [email protected]°.

The laser projector comes with an external electrical cabinet for all electronics and connections. Back-panel with independant integrated linearization for all colors and additional switches for rotating or mirroring the projection.

Tech Specs

Need a comprehensive view?
Toggle the series comparison chart
Configuration info
Manufacturer
Series LIGHTCUBE SERIES
Name LIGHTCUBE 851 RGB 10W
SKU 7640144994624
BEAM SPECS
Red Module
2 W 638 nm
Green Module
3 W 520nm
Blue Module
5 W 450nm
Manufacturer Stated Max Power 10.6W
Guaranteed Visible Power 10W
Full Angle Beam Divergence 1mrad
Beam Diameter 4mm
Color Output Full Color
Laser Source Diode
Laser Class 4
LASER RADIATION
AVOID EYE OR SKIN EXPOSURE TO DIRECT
OR SCATTERED RADIATION
SCANNER SPECS
Scanner Type Galvo
Max Scanner Speed [email protected]°
Max Scan Angle 60°
GENERAL SPECS
Operation Modes ILDA
Power Supply 110V - 220V AC 50/60Hz
Power Consumption 1,000W
Width 14in
Height 12in
Depth 8in
Accessories Ilda interlock connector, Safety unit pro
Compare every laser we offer in one place.
Click to download or print the PDF now!

COMPARISON CHART OF LIGHTCUBE SERIES

Model Price
HB-LASER LIGHTCUBE 851 RGB 3W
367.82
3.2W
2.6W
650mW
800mW
1.4W
638nm
520nm
450nm
3mm
3mm
3mm
0mrad
0mrad
0mrad
Full Color
60°°
I
$16,500.00
HB-LASER LIGHTCUBE 860 RGB 3.6W
36.11
4W
3.2W
600mW
1.6W
1.4W
638nm
520nm
450nm
3mm
3mm
3mm
1mrad
1mrad
1mrad
Full Color
80°
I
$14,499.00
HB-LASER LIGHTCUBE 851 RGB 5.5W
397.89
5.9W
5W
1.2W
1.5W
2.8W
638nm
520nm
450nm
4mm
4mm
4mm
0mrad
0mrad
0mrad
Full Color
60°
I
$19,990.00
HB-LASER LIGHTCUBE 851 RGB 10W
94.27
10.6W
10W
2W
3W
5W
638nm
520nm
450nm
4mm
4mm
4mm
1mrad
1mrad
1mrad
Full Color
60°
I
$31,399.00
HB-LASER LIGHTCUBE 863 RGB 22W
130.37
21.4W
19W
5W
6W
10.4W
638nm
520nm
450nm
6mm
6mm
6mm
1mrad
1mrad
1mrad
Full Color
54°
I
$36,299.00
* Operation modes :
  • ILDA over LAN : ILDA over LAN
  • Ethernet : Ethernet
  • S : Stand-Alone
  • M : Music
  • D : DMX
  • I : ILDA
  • L : LAN
  • SD : SD-card
  • WD : Wireless DMX
  • T : Text Mode
  • C : Clock Mode
  • LCD : Rear Panel LCD Display
  • A : ArtNET
  • FB4 : Pangolin FB-MAX Ethernet
Intensity Over Distance
Laser Module Power
Intensity Over Distance
Laser Module Power

Explore more options from the LIGHTCUBE SERIES
